PVDF membrane structure
MAS (Multiple Award Schedule) /
Product Classification
No.: 30231701 /
Detailed Item No.: 3023170101

Identification No. 23392500

  • Model Name : JBM11-1
  • Membrane Material : PVDF
  • Specifications : 5000 X 5000 X 5200
  • Unit Cost : KRW 309,000
  • Type : One-side supporting

Identification No. 23392503

  • Model Name : JBM12-1
  • Membrane Material : PVDF
  • Specifications : 5000 X 5000 X 3250
  • Unit Cost : KRW 320,000
  • Type : Two-sides supporting

Identification No. 23392504

  • Model Name : JBM12-2
  • Membrane Material : PVDF
  • Specifications : 10000 X 5000 X 4000
  • Unit Cost : KRW 335,000
  • Type : Two-sides supporting

Identification No. 23392505

  • Model Name : JBM12-3
  • Membrane Material : PVDF
  • Specifications : 10000 X 5000 X 3000
  • Unit Cost : KRW 339,000
  • Type : Two-sides supporting

Identification No. 23392506

  • Model Name : JBM13-1
  • Membrane Material : PVDF
  • Specifications : 10000 X 5000 X 3600
  • Unit Cost : KRW 365,000
  • Type : Three-sides supporting

Identification No. 23392507

  • Model Name : JBM13-2
  • Membrane Material : PVDF
  • Specifications : 10000 X 6000 X 4000
  • Unit Cost : KRW 359,000
  • Type : Three-sides supporting

Identification No. 23392508

  • Model Name : JBM14-1
  • Membrane Material : PVDF
  • Specifications : 25000 X 20000 X 6000
  • Unit Cost : KRW 310,000
  • Type : Four-sides supporting

PVF membrane structure
MAS (Multiple Award Schedule) / Product Classification
No.: 30231701 /
Detailed Item No.: 3023170102

Identification No. 23372570

  • Model Name : JBM21-1
  • Membrane Material : PVF
  • Specifications : 5000 X 5000 X 5200
  • Unit Cost : KRW 374,000
  • Type : One-side supporting

Identification No. 23372470

  • Model Name : JBM21-2
  • Membrane Material : PVF
  • Specifications : 5000 X 5000 X 4000
  • Unit Cost : KRW 400,000
  • Type : One-side supporting

Identification No. 23372469

  • Model Name : JBM21-3
  • Membrane Material : PVF
  • Specifications : 6000 X 6000 X 4500
  • Unit Cost : KRW 470,000
  • Type : One-side supporting

Identification No. 23372468

  • Model Name : JBM22-1
  • Membrane Material : PVF
  • Specifications : 5000 X 5000 X 3250
  • Unit Cost : KRW 375,000
  • Type : Two-sides supporting

Identification No. 23372467

  • Model Name : JBM22-2
  • Membrane Material : PVF
  • Specifications : 10000 X 5000 X 4000
  • Unit Cost : KRW 355,000
  • Type : Two-sides supporting

Identification No. 23372465

  • Model Name : JBM23-1
  • Membrane Material : PVF
  • Specifications : 10000 X 5000 X 3600
  • Unit Cost : KRW 395,000
  • Type : Three-sides supporting

Identification No. 23372464

  • Model Name : JBM23-2
  • Membrane Material : PVF
  • Specifications : 10000 X 6000 X 4000
  • Unit Cost : KRW 375,000
  • Type : Three-sides supporting

Identification No. 23372463

  • Model Name : JBM24-1
  • Membrane Material : PVF
  • Specifications : 25000 X 20000 X 6000
  • Unit Cost : KRW 394,000
  • Type : Four-sides supporting

PTFE membrane structure
MAS (Multiple Award Schedule) /
Product Classification
No.: 30231701 /
Detailed Item No.: 3023170103

Identification No. 23392524

  • Model Name : JBM31-1
  • Membrane Material : PTFE
  • Specifications : 5000 X 5000 X 5200
  • Unit Cost : KRW 389,000
  • Type : One-side supporting

Identification No. 23392525

  • Model Name : JBM31-2
  • Membrane Material : PTFE
  • Specifications : 5000 X 5000 X 4000
  • Unit Cost : KRW 440,000
  • Type : One-side supporting

Identification No. 23392527

  • Model Name : JBM32-1
  • Membrane Material : PTFE
  • Specifications : 5000 X 5000 X 3250
  • Unit Cost : KRW 399,000
  • Type : Two-sides supporting

Identification No. 23392528

  • Model Name : JBM32-2
  • Membrane Material : PTFE
  • Specifications : 10000 X 5000 X 4000
  • Unit Cost : KRW 430,000
  • Type : Two-sides supporting

Identification No. 23392529

  • Model Name : JBM32-3
  • Membrane Material : PTFE
  • Specifications : 10000 X 5000 X 3000
  • Unit Cost : KRW 430,000
  • Type : Two-sides supporting

Identification No. 23392530

  • Model Name : JBM33-1
  • Membrane Material : PTFE
  • Specifications : 10000 X 5000 X 3600
  • Unit Cost : KRW 430,000
  • Type : Three-sides supporting

Identification No. 23392531

  • Model Name : JBM33-2
  • Membrane Material : PTFE
  • Specifications : 10000 X 6000 X 4000
  • Unit Cost : KRW 369,000
  • Type : Three-sides supporting

Identification No. 23392532

  • Model Name : JBM34-1
  • Membrane Material : PTFE
  • Specifications : 25000 X 20000 X 6000
  • Unit Cost : KRW 390,000
  • Type : Four-sides supporting

Identification No. 23392533

  • Model Name : JBM34-2
  • Membrane Material : PTFE
  • Specifications : 10000 X 10000 X 5500
  • Unit Cost : KRW 420,000
  • Type : Four-sides supporting

Other membrane structures
MAS (Multiple Award Schedule) /
Product Classification
No.: 30231701 /
Detailed Item No.: 3023170104

Identification No. 23392546

  • Model Name : JBM41-1
  • Membrane Material : ECM
  • Specifications : 5000 X 5000 X 5200
  • Unit Cost : KRW 339,000
  • Type : One-side supporting

Identification No. 23392547

  • Model Name : JBM41-2
  • Membrane Material : ECM
  • Specifications : 5000 X 5000 X 4000
  • Unit Cost : KRW 380,000
  • Type : One-side supporting

Identification No. 23392549

  • Model Name : JBM42-1
  • Membrane Material : ECM
  • Specifications : 5000 X 5000 X 3250
  • Unit Cost : KRW 350,000
  • Type : Two-sides supporting

Identification No. 23392550

  • Model Name : JBM42-2
  • Membrane Material : ECM
  • Specifications : 10000 X 5000 X 4000
  • Unit Cost : KRW 365,000
  • Type : Two-sides supporting

Identification No. 23392552

  • Model Name : JBM43-1
  • Membrane Material : ECM
  • Specifications : 10000 X 5000 X 3600
  • Unit Cost : KRW 385,000
  • Type : Three-sides supporting

Identification No. 23392553

  • Model Name : JBM43-2
  • Membrane Material : ECM
  • Specifications : 10000 X 6000 X 4000
  • Unit Cost : KRW 360,000
  • Type : Three-sides supporting

Membrane replacement in a component - membrane structure
MAS (Multiple Award Schedule) / Applicable to traditional markets, outdoor stages, and pergolas

Identification No. 23657377

  • Model Name : JBM-M4
  • Membrane Material : ECM(other)
  • Specifications : 1000 X 1000
  • Unit Cost : KRW 209,000
  • Type : For membrane replacements

Identification No. 23657378

  • Model Name : JBM-M3
  • Membrane Material : PTFE
  • Specifications : 1000 X 1000
  • Unit Cost : KRW 264,000
  • Type : For membrane replacements

Identification No. 23657379

  • Model Name : JBM-M2
  • Membrane Material : PVF
  • Specifications : 1000 X 1000
  • Unit Cost : KRW 244,000
  • Type : For membrane replacements

Identification No. 23657380

  • Model Name : JBM-M1
  • Membrane Material : PVDF
  • Specifications : 1000 X 1000
  • Unit Cost : KRW 204,000
  • Type : For membrane replacements
