ETFE (Ethylene tetrafluoroethylene) is a high-polymer material containing fluorinated thermoplastic
that is eco-friendly and has excellent durability and penetrability.
ETFE Technical Data
| Mechanical Properties |
Tensile strength: 40 MPa or greater Tearing strength: 400 N/mm or greater Elongation: 300% or more |
|---|---|
| Durability Performance |
25 years or longer Heat resistance, weather resistance, chemical resistance, thermal resistance: Good Initial properties do not change even after long-term usage |
| Transparency |
Transparency of ETFE is between 40% (min) - 97% (max) |
|---|---|
| Thermodynamic Performance, U-Values (W m/K) |
Single layer: approx. 7.0 Dual cushion: approx. 3.5 Triple cushion: approx. 2.0 |
